Spectrophotometers

Micro controller Based Instrument having range 190-1100 nm, On-screen standard curve display on large 5 inches graphic LCD, 1.0 nm Spectral Bandwidth, 1200 Lines/mm Grating, 8 position auto cell changer, Wavelength Scanning, PC connectivity through USB port & direct printer connectivity using parallel port interface. It has facility for WL Scan, Kinetics, Multi Wavelength & DNA/Protein modes,inclusive of PC software.

Micro controller Based instrument having range 190 to 1100 nm with 24 x 2 line LCD display, two quartz cuvettes, 18 touch keys, base line correction, source optimization & electronic calibration etc. It has facility for measurement of %T, Abs. Conc., K-Factor and multi component analysis. A set of 2 Quartz & Set of 4 Glass Cuvettes. The operating modes are single/multi-wave length, wavelength scan,time scan etc. PC Software at extra cost

Micro controller Based instrument having range 190 to 1100nm with basic PC software and 4 position cell changer. It has graphic LCD for display of kinetic,concentration graphs. PC connectivity through USB Port & direct printer connectivity using parallel port interface. Extensive elaborate keyboard for ease of operator. Sample compartment can accommodate upto 100mm cuvettes(optional). Basic modes like %T,Abs, Concentration, Kinetics available. Wavelength Scanning and DNA/Proteins can be done using advanced professional PC Software Models Available are -

• in Range 200-1000 nm

• in Range 190-1000 nm

• It has 16 x 2 line LCD data display and motorized wavelength selection on 4 digit LED display. It has quad sample holder with 4 position selector control for 10 mm path length cuvettes. Facility has been provided for 100 sample data storage and interface with any centronic printer.

Range 190 to 1000 nm with facility for automatic Concentration, %T & Absorbance measurements. Motorized Micro controller based Wavelength Selection, 4 digit LED display for Wavelength, 3½ digit LED data display. It has 4 position sample holder with position selector control for 10 mm path length cuvettes. A set of 2 quartz cuvettes is provided.

Range 320-1100 nm. On-screen standard curve display on Graphic LCD, PC connectivity through USB [port & direct printer connectivity using parallel port interface, Auto zero and blank. 0.1 nm wavelength Scanning can be done using professional PC Software

Range 325-1000nm. 4 digit Large LED display, PC connectivity through USB port & direct printer connectivity using parallel port interface, Auto zero and blank, 2nm wavelength resolution, with basic PC software

Range 340–960 nm with facility for automatic concentration, %Transmission & Absorbance measurement. Simultaneous display of wave length with 1nm resolution on 3 digit LED display and data on a 3½ LED display are available. Provision for 10 mm & 50 mm cuvettes holders with adapter is available. A set of 10 mm path length glass cuvette is supplied with the instrument. 50mm cuvette set can be provided at extra cost.
