The laboratory pulveriser is a disc type grinder, designed to grind virtually any material to produce a fine mesh sample in one operation. The instrument is useful for assaying, mining and for metallurgical, quarrying, aggregate processing, chemical, geological and industrial laboratories. It is a self contained grinder, with a rotary disc, having a planetary movement in a vertical plane. This feature gives added life to the moving parts and produces a sample of uniform fineness.
- Grinding is done between two discs-one stationery and the other revolving eccentrically at high speed. The discs are made from heat treated mehanite metal. With the help of a convenient hand wheel, the size of the final product can be adjusted. This can be done, even while the machine is in operation. A self locking device holds the hinged grinding chamber in place and affords easy and quick access to it, for removal of ground samples and for cleaning. The Pulveriser has a capacity of reducing about half of a kg. of a quartz type sample to 100 mesh in about a minute. The Pulveriser is supplied complete with a 3 H.P. motor, a starter, a "V" belt pulley drive and mounting. Wired for 400 v, 3 Ph, 50 Hz.
Maximum Feed size------6mm.
Size of Finished Product------100 mesh.
