- Variable speed drive with DC/Servo drive options.
- Provision for automatic identificatin & thereby interchangeability of load cells.
- Provision of different clamping devices to suit specific test requirement.
- Safely interlock by enf limit switches & by overload sensing.
- Load Cells - Universal load cells of following capacities. 50N, 100N, 250N, 500N, 1kN, 10kN, 25kN, 50kN, 100kN, Any other load cell can be offered on requirement.
Option -1 Measuring System MP
- Extensometers with Electronic Interface & Evaluation Software .M-2 Stain gauge type with 2mm extension and guage length 25mm & 50 mm. It measures important parameter like 0.1%, 0.2% proof stress and usable upto dia/flat 40 mm Long travel Extensometer for rubber test.offers following extensometers with electronic interface & evaluation software .M-2 Stain gauge type with 2mm extension and guage length 25mm & 50 mm. It measures important parameter like 0.1%, 0.2% proof stress and usable upto dia/flat 40 mm Long travel Extensometer for rubber test.
- Microprocessor based system with digital display of load and displacement / extension it is having membrane keyboard for entering necessary input data and for reading results, Printout of Load v/s. Displacement or Stress v/s. Strain is available as standard feature. Option 2 - Measuring System PC
- It is PC based card system where two PCB's are directly fitted into PC slot, Load & Displacement are shown on computer screen, Input data is feed by means of computer keyboard. Test is automatically completed & test result are displayed on computer screen.
- Maximum Test load - 5 kN, 10 kN, 20 kN, 50 kN, 100 kN
- Load Measurement - By means of exchangeable strain gauge based load cell
- Load Measuring Range and Accuracy- ± 1 % on indicated load from 2 % to 100% of load capacity
- Maximum Crosshead Stroke-1000 mm without load cell & grips
- Distance between Columns-450 mm
- Drive System Option - DD with DC drive - 1:10 speed ratio 5 - 50 mm / min, 25 -250 mm / min, 50- 500 mm / min
- (Any other speed range available on request)
- Drive System Option - SD with servo drive - 0.5 mm to 500 mm/min (Any other speed range available on request)
- Power Supply - 230 V AC / 50Hz, 1 Ph for 5, 10 & 20 KN
- 415 V AC / 50Hz, 3 Ph for 50& 100KN
- Option -1 Measuring System MP
- Panel Crosshead Display Resolution - 0.1 mm by means of rotary encoder
- Load range & Resolution - 1 / 10000 from 0 - 40 % of range and 1 / 4000 from 40- 100% of range
- Option - 0.1mm crosshead Dis. Resolution (0.01 Optional) / Serial Software.
- Option 2 - Measuring System PC
- Crosshead Display Resolution - 0.1 mm by means of rotary encoder
- Load range & Resolution - + 1 / 25000 Single range.
